Mi-T-M-HAE-2503-0E4G industrial air compressor on a white background

Mi-T-M HAE-2503-0E4G | 2500 PSI-2.8 GPM Electric Stationary Hot Water Pressure Washer

by Mi-T-M
Save $1,440.00
$14,997.00
$13,557.00

Notify me when back in stock

Veteran Owned Badge No Hidden Fees Badge Authorized Dealer Badge Manufacturer Warranty Badge Free Shipping Badge
Every job is different. Let’s talk about yours - Call Now.
Phone Icon
Call / Text: (910) 218-9010
Email Icon
Email: sales@americancleaningequipment.com
Chat Icon
Chat: Click "Message Us" in the lower right to chat now!
Sales tax will be applied to all North Carolina orders.
Description

Mi-T-M HAE Series All-Electric Belt Drive Hot Water HAE-2503-0E4G

Mi-T-M HAE-2503-0E4G

The HAE Series pressure washer offers an all-electric design with a patented heat exchanger that delivers reliable and efficient hot water performance.

Pump

Factory preset unloader

Stainless-steel and brass unloader valve

Forged brass manifold

Thermal relief valve

Motor

Open drip-proof electric motor with manual thermal overload protection

On/off power switch

Frame

Stainless-steel base and frame with rubber isolators

Component

Time delay shutdown

Heat Exchanger

Used for consistent and efficient on-demand hot water

120°F to 130°F temperature rise above in-take water, obtained within 3 to 5 minutes

Adjustable thermostat

On/off power switch

Powder coated steel frame

Patented cartridge design

Low maintenance, stainless-steel coils in aluminum casings for maximum efficiency

Eliminates constant cleaning and heat loss

Unit Includes

Quick connect nozzles - 0°, 15°, 25° and 40°

External downstream detergent injector with detergent nozzle

50-foot x 3/8-inch wire-braided black hose

Adjustable pressure insulated dual lance with trigger gun

 Mi-T-M WP-4200-0MKB

Additional Options

Options

Options - must be ordered with unit and cannot be added later.

HX-0298 Remote Box

Adds control box, may be mounted away from unit to control on/off, controls the hot water heater and cold water pump

HX-0307 Auto Start/Stop

When trigger gun is released, the timer will turn unit off; when trigger gun is pulled, unit will restart

Mi-T-M HAE-2503-0E4G Manual

Mi-T-M HAE-2503-0E4G Manual

 Mi-T-M HAE-2503-0E4G Manual
Specifications
PSI 2500
GPM 2.8
Displacement/ Engine 6.0 HP, 480V, 3Ø
Unit Amperage 68.0A
Unloader Adjustable Pressure
Pump General
Heater kW 48
Temperature Rise 120°F
Net Weight 625.00 lbs.
Length 36.00 in.
Width 25.00 in.
Height 49.00 in.
